BilJax Towable Articulating Man Lift 45'

The Haulotte 4527A tow-behind manlift is specifically designed to give maximum reach performance from the most compact chassis possible. By utilizing its versatile telescopic upper boom, the 4527A towable cherrypicker delivers unrivalled working outreach, especially at lower levels where it’s needed most. Hydraulically operated outriggers with automatic leveling make setting up this platform lift both quick and easy. Able to be powered by either 120V outlet, or onboard batteries this lift can be used even in the most remote locations.

  • Lift capacity 500 lbs.
  • Weight 4200 lbs
  • Built-in battery bank

Description

The Haulotte 4527A tow-behind manlift is specifically designed to give maximum reach performance from the most compact chassis possible. By utilizing its versatile telescopic upper boom, the 4527A towable cherrypicker delivers unrivalled working outreach, especially at lower levels where it’s needed most. Hydraulically operated outriggers with automatic leveling make setting up this platform lift both quick and easy. Able to be powered by either 120V outlet, or onboard batteries this lift can be used even in the most remote locations. This telescoping boom lift is the ideal machine for any number of aerial access jobs including tree work, commercial and residential roof repair and replacement, Christmas decoration lighting, light and sign post installation and repair, just to name a few. It’s portability and ease of transport, user friendly controls, and industry standard safety features allows you to focus on your task at hand making for the perfect towable lift rental unit.

**This item requires proof of liability insurance to rent. This is usually a homeowner’s policy for home use, or a business liability policy.



Specifications

  • Working height 51 ft.
  • Platform height 45 ft.
  • Horizontal outreach (from centerline) 27 ft.
  • Horizontal outreach (from edge of footpad) 21 ft.
  • Up and over height 20 ft. 9 inches
  • Turntable rotation 350° non-continuous
  • Widest Point 13 ft. 9 inches
  • Lift capacity 500 lbs.
  • Leveling capability 12.5 °
  • Platform size 4 ft 1 in x 2 ft. 9 inches
  • Length – stowed 20 ft. 8 inches
  • Width stowed 5 ft. 6 inches
  • Height stowed 6 ft. 8 inches
  • Tow speed rating 65 mph
  • Tongue weight (no options) 335 lbs.
  • Weight 4200 lbs
  • 120V Wall Outlet
  • Built-in battery bank
